Name: Geometric modeling in computerAided Geometric design
Brand: U. EAFIT
SKU: 326784

☑️ ENVÍO GRATIS a toda Colombia por compras superiores a $ 79.000 (*)

SINOPSIS DEL LIBRO:

This book presents conventions, mathematical concepts, definitions and applications central to the geometric modeling of solids, shells and wires (engineering jargon) embedded in 3D space. Currently, software is available for geometric modeling of technical or natural scenarios. However, the models built frequently fail in supporting the subsequent engineering computing and simulations. Only after repeated iterations and re-design, the models permit engineering / science simulations. This book endows the reader with the basic mathematical concepts needed to ensure that the geometric models indeed stand the stages of physics simulation, manufacturing, etc., and rapidly applies the concepts on engineering and science geometric models.

Características:

Atributos LU

Año de Edición

2018

Descatalogado

Tipo

Libro

Autor

Oscar Ruiz Salguero y Carlos Cadavid Moreno

Colección

Académica

ISXN

9789587204315

Idioma

Español

Núm. Páginas

130

Peso (Físico)

250

Tamaño (Físico)

17.5 x 25 cm

Acabado (Físico)

Tapa Rústica

Título

Geometric modeling in computer-Aided Geometric design

Biografía del Autor

Tabla de Contenido

1 Introduction

2 Mathematical Background

2.1 Definition. Bijective Functions and Isomorphisms

2.2 Definition. Metric or Distance Function

2.3 Definition. Open Ball

2.4 Definition. Open Set vs. Closed Set

2.5 Definition. Boundary, Interior, Regular Sets

2.6 Definition. Topology and Topological Space

2.7 Definition. Neighborhood

2.8 Definition. Neighborhood Topology

2.9 Definition. Disks and Half-disks 82 and S1

2.10 Definition. 2-Manifold in R3

2.11 Definition. 2-Manifold with Border in R3

2.12 Definition. 1-Manifold in R3

2.13 Definition. 1-Manifold with Border in R3

2.14 Examples of Non-manifold Topologies

2.15 Definition. Connected Set in R3

3 B-Reps

3.1 Solid (BODY) in R3

3.2 LUMP in R3

3.3 SHELL

3.4 FACE

3.5 LOOP

3.6 EDGE

3.7 VERTEX

3.8 Example. Pre-Columbian Shape

3.9 Examples Non-Manifold

3.10 Example. Manifold Preservation in Parametric CAD

3.10.1 Questions on Boundary - Representation

3.11 Example. Repair of Extrusion of Non-manifold Sections

3.11.1 Extrusion of Non-Manifold Cross Section

3.11.2 Manifold Repair

3.12 Exam Example. Repair of Non-manifold Pyramid

3.12.1 Context

3.12.2 B-Rep example

3.12.3 Solution

3.13 22D Elements

4 Triangular B-Reps

4.1 Definition. Convex Set

4.2 Definition. Convex Hull

4.3 Definition. k - simplices

4.3.1 Low Dimension Simplices

4.3.2 Inventory of i-Faces in a k-Simplex

4.3.3 Example. Simplicial Complex

4.4 Boundary Representation for Triangle-Based Meshes

5 CSG Modeling

5.1 Constructive Solid Geometry tree

5.2 Primitives operands

5.3 Unary Operations

5.4 Binary operators

5.4.1 Regularized Set Operations

5.5 Example CSG

5.5.1 Primitive operands

5.5.2 Unary operations

5.5.3 Binary operations

5.5.4 CSG Tree structure

5.6 Observations

6 Enumerations

6.1 Scalar Fields

6.2 Uniform Cell

6.2.1 Fixed Grids

6.2.2 Medical Imaging

6.3 Non-Uniform Cell Decompositions. Quadtrees

6.3.1 Example Quadtree 3 Levels

6.3.2 Example Quadtree 4 Levels

6.3.3 Observations on Quadtrees

6.3.4 Quadtree Boolean Operations

6.3.5 Theoretical Discussion

6.3.6 Octrees.

7 Acknowledgments

Libros Impresos 3x2

Botón empaque navideño

Todos los libros impresos-1-2022

Flash Sale 20off - 23marzo - 4

ISBN: 9789587204315

Referencia: 326784

Compra el libro

Libro Impreso

U. EAFIT

Autor: Oscar Ruiz Salguero y Carlos Cadavid Moreno

Cargando comentarios…

$ 40.000 COP
